SYSTEM REQUIREMENTS

WINDOWS

Operating System
Microsoft Windows XP(64bit는 추후 지원 불가), Windows Vista(64bit 호환), Windows 7, Windows 8

CPU/Clock
900MHz AMD or Pentium. (1.5 GHz or higher recommended)

Memory (RAM)
512 MB (more recommended)


APPLE MAC

Operating System
Mac OS X 10.4.x or later

Mac OS X 10.4.11은 Saffire MixControl 1.8 버전 설치 필요

Mac OS X 10.5는 Saffire MixControl 2.4 버전 설치 필요

CPU/Clock
PowerPC G4/Dual 1 GHZ or faster or any Intel-based Mac

Memory (RAM)
512 MB (more recommended)


PERFORMANCE SPECIFICATIONS

Microphone Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1 dB
?THD+N: 0.001% (measured at 1kHz with a 20Hz/22kHz bandpass filter)
?Noise: EIN > 125dB (128dB analogue to digital) (measured at 60dB of gain with 150 Ohm termination (20Hz/22kHz bandpass filter)

Line Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1dB
?THD+N: < 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)
?Noise: -90dBu (22Hz/22kHz bandpass filter)

Instrument Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1dB
?THD+N: 0.004% (measured with 0dBu input and 20Hz/22kHz bandpass filter)
?Noise: -87dBu (20Hz/22kHz bandpass filter)

Conversion performance
?Dynamic Range = 110dB (A-wieghted)
?Clock jitter < 250 picoseconds
?THD+N AMPL = -109dBFS 'A' weighted

Front and Rear Connectivity

Analogue Channel Inputs (Inputs 1-8)
?Mic inputs 1-8 on rear XLR?s.
?Line inputs 1-8 on rear 1/4?TRS.
?Instrument inputs on channels 3 and 4 (separate front panel 1/4?TRS).

Notes
?Individual switchable High Pass Filter on all inputs.
?Phase switch on inputs 3, 5 and 7.
?Input Pad on inputs 3 and 4 = -10dB.

Analogue Outputs
?Line level 10 x 1/4?TRS Jack.

Notes
Outputs Monitor 1 and 2 have anti-thump protection circuitry.

Digital I/O
?SPDIF input and output (RCA phono) on rear panel, (24-bit, 44.1 - 192kHz),
output transformer isolated.
?Optional AES output mode with professional channel status and voltage levels
on SPDIF output (isolated and balanced). [Currently not implemented, a future update will include this feature].
?2 x ADAT In / Out 16 channels (44.1 / 48kHz), 8 channels S-MUX (88.2 / 96kHz),
4 channels S-MUXII (176.4 / 192kHz).
?ADAT Input and Output 2 can be re-configured to be optical SPDIF input /
output via control panel.
?BNC Word clock input and output (75 ohms).

MIDI I/O
?1 in / 1 out (16 channels) on rear panel.

HEADPHONE MONITORING
?2 x 1/4?TRS Jack on front panel (mirrors outputs 7-8 and 9-10).
NOTE: These are high power headphone drivers.

Other I/O
?2 6-pin Firewire sockets
?2 Standard 5-pin DIN MIDI connectors: In and Out
?IEC mains power input connector


Weight and Dims
?5kg / 11 Ibs
?350mm / 13.8' (W) x 90mm / 3.6' (H) x 235mm /9.3' (D)
