SYSTEM REQUIREMENTS
WINDOWS
Operating System
Microsoft Windows XP(64bit는 추후 지원 불가), Windows Vista(64bit 호환, 추후 지원 불가), Windows 7, Windows 8
CPU/Clock
900MHz AMD or Pentium. (1.5 GHz or higher recommended)
Memory (RAM)
512 MB (more recommended)
APPLE MAC
Operating System
Mac OS X 10.4.x or later
Mac OS X 10.4.11은 Saffire MixControl 1.8 버전 설치 필요
Mac OS X 10.5는 Saffire MixControl 2.4 버전 설치 필요
PowerPC G4/Dual 1 GHZ or faster or any Intel-based Mac
Memory (RAM)
512 MB (more recommended)
PERFORMANCE SPECIFICATIONS
Microphone Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1 dB
?THD+N: 0.001% (measured at 1kHz with a 20Hz/22kHz bandpass filter)
?Noise: EIN > 125dB (128dB analogue to digital) (measured at 60dB of gain with 150 Ohm termination (20Hz/22kHz bandpass filter)
Line Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1dB
?THD+N: < 0.001% (measured with 0dBFS input and 22Hz/22kHz bandpass filter)
?Noise: -90dBu (22Hz/22kHz bandpass filter)
Instrument Inputs
?Frequency Response: 20Hz - 20kHz +/- 0.1dB
?THD+N: 0.004% (measured with 0dBu input and 20Hz/22kHz bandpass filter)
?Noise: -87dBu (20Hz/22kHz bandpass filter)
Conversion performance
?Dynamic Range = 110dB (A-wieghted)
?Clock jitter < 250 picoseconds
?THD+N AMPL = -109dBFS 'A' weighted
Front and Rear Connectivity
Analogue Channel Inputs (Inputs 1-8)
?2 Mic/Line/Inst Combo XLR (Inputs 1 and 2)
?6 Mic/Line Combo XLR (Inputs 3-8)
?Automatic switching of Mic / Line (e.g. inserting a jack switches from Mic to either Line or Instrument)
Digital Channel Inputs (Inputs 9-18) 44.1-96kHz
?Stereo S/PDIF input on RCA
?8 ADAT inputs on Optical Connector, reduces to 4 inputs at 88.2/96kHz ?Optical input can be switched to S/PDIF 3/4 in software preferences (ADATs disabled)
Analogue Audio Outputs (Outputs 1-10)
?8 ?? TRS Jack (Outputs 3-10)
?2 monitor mix outputs on ?? TRS Jack (Outputs 1 and 2)
?Stereo headphones mix 1 on ?? TRS (also routed to outputs 7 & 8)
?Stereo Headphones mix 2 on ?? TRS (also routed to outputs 9 & 10)
Digital Channel Outputs (Outputs 11-20) 44.1-96kHz
?Stereo S/PDIF output on RCA
?8 ADAT outputs on Optical Connector, reduces to 4 outputs at 88.2/96kHz ?Optical output can be switched to S/PDIF 3/4 in software preferences (ADATs disabled)
Other I/O
?2 6-pin Firewire sockets
?2 Standard 5-pin DIN MIDI connectors: In and Out
?IEC mains power input connector
Weight and Dims
?3kg / 6.6Ibs
?482mm / 19' (W) x 45mm / 1.8' (H) x 265mm /10.4' (D)
