| 개요 |
| I/O | 가상 전원 | + 48 V | + 48 V |
| Input Channels | Mono[MIC/LINE] | 2 including HEADSET MIC (Plug-in Power) | 1 including HEADSET MIC (Plug-in Power) |
| Stereo[LINE] | 2 | 1 including Guitar input (Mono) |
| AUX | 1 | 1 |
| Output Channels | STEREO OUT | 1 | - |
| MONITOR OUT (모니터 출력) | 1 | 2 |
| PHONES | 2 including HEADSET PHONES | 2 including HEADSET PHONES |
| Bus | Stereo: 1 | Stereo: 1 |
| Input Channel Function | PAD | 26 dB | 26 dB |
| PEAK LED | LED turns on when the signal reaches 3 dB below clipping level | LED turns on when the signal reaches 3 dB below clipping level |
| 내장 프로세서 | DSP | CH1: COMP / EQ, EFFECT (SPX Reverb) ; CH2: AMP SIM, EFFECT (SPX Reverb) | CH1: COMP / EQ, EFFECT (SPX Reverb) |
| Level Meter | USB Output Level; 2 x 2 point LED meter [PEAK, SIG] | USB Output Level; 2 x 2 point LED meter [PEAK, SIG] |
| USB | USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit | USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit |
| 일반 사양 |
| 전원 요구 사항 | DC 5 V, 500 mA | DC 5 V, 500 mA |
| 전력 소비 | Max. 2.5 W | Max. 2.5 W |
| 시스템 요구사항 | OS | Windows 7 or later / Mac OS X 10.7 or later | Windows 7 or later / Mac OS X 10.7 or later |
| 면적 | W | 155 mm (6.1') | 129 mm (5.1') |
| H | 63 mm (2.5') | 63 mm (2.5') |
| D | 202 mm (8.0') | 202 mm (8.0') |
| 순 무게 | 1.0 kg (2.2 lbs) | 0.8 kg (1.8 lbs) |
| Options | Foot Switch: FC5, Mic Stand Adaptor: BMS-10A | Foot Switch: FC5, Mic Stand Adaptor: BMS-10A |
| 기타 | Foot Switch: EFFECT Mute on / off, Operating Temperature: 0 to + 40 °C | Foot Switch: EFFECT Mute on / off, Operating Temperature: 0 to + 40 °C |
